Parameter length |
2100mm |
|
Height |
642mm |
|
Wingspan |
1464mm |
|
Load Compartment |
Top Bottom: 100mm, Top Bottom: 200mm Height: 175mm, Payload Bay Length: 320mm |
|
Standard Tank Capacity |
20L |
|
Mission Payload (fuel included) |
≥22kg |
|
PNP Weight |
16±0.3kg (machine weight) |
|
Maximum Safe Takeoff Weight |
40kg |
|
Maximum Speed |
110m/s |
|
Cruising Speed |
70m/s |
|
Endurance |
620g/min |
|
Endurance |
40min (carrying 5.5kg, take off weight 40kg) 35min(carrying 7kg, take off weight 40kg) |
|
Stall |
45m/s |
|
Maximum Climb Rate |
15m/s |
|
Practical Ceiling |
3500m |
|
Practical Ceiling |
≥7000m (Fixed wing mode) |
|
Use Temperature |
-20℃~55℃; Can fly in light rain |
|
Wind Resistance Class |
13m/s (Force 6 wind) |
|
Box Parameter |
1650*820*450 mm 36kg |
|
Box Weight |
36kg |
