Overall Length |
2260mm |
|
Height |
800mm |
|
Wingspan |
3920mm |
|
Load Compartment Size |
550*260*270mm |
|
Outer Packaging Box Size |
2155*800*660mm |
|
Engine |
DLE60 EFI |
|
Main Propeller |
24*12 inches |
|
Rotor Propeller |
29*8.7 inches |
|
Standard Fuel Tank Capacity |
10L |
|
Max Load |
10kg |
|
Max Safe Takeoff Weight |
35kg |
|
Max Horizontal Speed |
24-40m/s |
|
Max Endurance |
8h/6kg 10h/2kg |
|
Max Climb Rate |
4m/s |
|
Operating Altitude |
5000m |
|
Operating Temperature |
-20℃-50℃ |
|
Wind Resistance |
Level 5 takeoff and landing/Level 6 flight |
