FD400 is a conventional pure electric tail push vertical takeoff and landing fixed wing UAV with high strength and light weight, which is suitable for a variety of application scenarios such as long operation time and fast task load switching. Make full use of the photoelectric pod, LiDAR, and other task loads to complete the inspection, measurement, and monitoring of the target area
| Total Length |
2263mm (including motor) |
|
Altitude |
552mm |
|
Wingspan |
4005mm |
|
Max Safe Takeoff Weight |
30kg |
|
Max Payload |
10kg |
|
Max Cruising Speed |
33m/s |
|
Standard Cruising Speed |
24m/s |
|
Endurance |
4h@5kg |
|
Stall |
18m/s |
|
Max Climb Rate |
4m/s |
|
Max Take-Off Altitude |
3500m (vertical take-off and landing mode) |
|
Practical Ceiling |
4500m (Fixed wing mode) |
|
Min Circling Radius |
200 m (plateau safe turning radius is not less than 250m) |
|
Service Temperature |
-20℃~45℃; Can fly in light rain (rainfall ≤10mm/24h) |
|
Wind Resistance Of Fixed Wing Mode |
13m/s (Force 6 wind) |
|
Wind Resistance Of Quadrotor Mode |
10m/s (Force 5 wind) |
|
Box Size |
1840*720*600mm |
|
Box Weight |
48kg |
|
Body Protection Class |
IPX4 |
